Camera
|
|
Image Sensor
|
1/2.5” 8Megapixel progressive scan CMOS
|
|
Effective Pixels
|
3840(H)x2160(V)
|
|
RAM/ROM
|
512MB/32MB
|
|
Scanning System
|
Progressive
|
|
Electronic Shutter Speed
|
Auto/Manual, 1/3~1/100000s
|
|
Minimum Illumination
|
0.05Lux/F1.4 (Color,1/3s,30IRE)
0.2Lux/F1.4 (Color,1/30s,30IRE)
0Lux/F1.4(IR on)
|
|
S/N Ratio
|
More than 50dB
|
|
IR Distance
|
Distance up to 50m (164ft)
|
|
IR On/Off Control
|
Auto/ Manual
|
|
IR LEDs
|
4
|
|
Lens
|
|
Lens Type
|
Motorized/ Auto Iris(DC)
|
|
Mount Type
|
Board-in
|
|
Focal Length
|
2.7mm~12mm
|
|
Max. Aperture
|
F1.4
|
|
Angle of View
|
H:110°~40° , V:58°~23°
|
|
Optical Zoom
|
4x
|
|
Focus Control
|
Motorized
|
|
Close Focus Distance
|
0.3m
|
|
DORI Distance
|
Lens
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
W
|
85m(280ft)
|
34m(112ft)
|
17m(56ft)
|
8.5m(28ft)
|
|
T
|
228m(748ft)
|
91m(299ft
|
46m(151ft)
|
23m(75ft)
|
|
Pan/Tilt/Rotation
|
|
Pan/Tilt/Rotation Range
|
Pan:0˚~360˚; Tilt:0˚~90˚; Rotation:0˚~360˚
|
|
Intelligence
|
|
IVS
|
Tripwire, Intrusion, Object Abandoned/Missing
|
|
Advanced Intelligent Functions
|
Face Detection
|
|
Video
|
|
Compression
|
H.265+/H.265/H.264+/H.264
|
|
Streaming Capability
|
3 Streams
|
|
Resolution
|
4K(3840×2160)/ 6M(3072×2048)/5M(3072x1728)/ 5M(2592×1944)/ 4M(2688×1520)/ 3M(2048x1536)/ 3M(2304×1296)/ 1080P(1920×1080)/1.3M(1280x960)/ 720P(1280×720)/ D1(704×576/704×480)/
VGA(640×480)/ CIF(352×288/352×240)
|
|
Frame Rate
|
Main Stream: 4K(1~15fps)/3M(1~25/30fps)
|
|
Sub Stream: D1(1~25/30fps)
|
|
Third Stream: 720P(1~25/30fps)
|
|
Bit Rate Control
|
CBR/VBR
|
|
Bit Rate
|
H.264: 24K ~ 10240Kbps H.265: 14K ~ 9984Kbps
|
