Camera
|
|
Image Sensor
|
1/1.8” 8Megapixel progressive CMOS
|
|
Effective Pixels
|
3840(H) x2160(V)
|
|
RAM/ROM
|
512MB/128MB
|
|
Scanning System
|
Progressive
|
|
Electronic Shutter Speed
|
Auto/Manual, 1/3~1/100000s
|
|
Minimum Illumination
|
0.004Lux/F1.9( Color,1/3s,30IRE)
0.09Lux/F1.9 Color,1/30s,30IRE)
0Lux/F1.9(IR on)
|
|
S/N Ratio
|
More than 50dB
|
|
IR Distance
|
Distance up to 60m(197ft)
|
|
IR On/Off Control
|
Auto/ Manual
|
|
IR LEDs
|
4
|
|
Lens
|
|
Lens Type
|
Motorized
|
|
Mount Type
|
Board-in
|
|
Focal Length
|
3.7mm~11mm
|
|
Max. Aperture
|
F1.9
|
|
Angle of View
|
H:112°~46°, V:60°~26°
|
|
Focus Control
|
Motorized
|
|
Close Focus Distance
|
0.2m(0.66ft)
|
|
DORI Distance
|
Lens
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
W
|
83m(272ft)
|
33m(108ft)
|
17m(56ft)
|
8m(26ft)
|
|
T
|
190m(623ft)
|
76m(249t)
|
38m(125ft)
|
19m(62ft)
|
|
PTZ
|
|
Pan/Tilt Range
|
Pan:0° ~355° ;Tilt:0° ~75° ;Rotation:0° ~355°
|
|
Intelligence
|
|
Event Trigger
|
Motion detection, Video tampering, Scene changing, Network disconnection, IP address conflict, Illegal access, Storage anomaly
|
|
IVS
|
Tripwire, Intrusion
|
|
Video
|
|
Compression
|
H.265/H.264H/MJPEG(Sub Stream)
|
|
Smart Codec
|
Support H.265+/H.264+
|
|
Streaming Capability
|
2 Streams
|
|
Resolution
|
4K(3840×2160)/6M(3072×2048)/5M(2560×1920)/
3M(2048x1536)/3M(2304×1296)/
1080P(1920×1080)/1.3M(1280x960)/
720P(1280×720)/D1(704×576/704×480) /VGA(640×480)/CIF(352×288/352×240)
|
|
Frame Rate
|
Main Stream: 4K (1~25/30fps)
|
|
Sub Stream: D1(1~25/30fps)
|
|
Bit Rate Control
|
CBR/VBR
|
|
Bit Rate
|
H.264: 32Kbps~8192Kbps
H.265: 16Kbps~8192Kbps
|
