Camera
|
|
Image Sensor
|
1/3” 4Megapixel progressive CMOS
|
|
Effective Pixels
|
2688(H) x1520(V)
|
|
RAM/ROM
|
512MB/32MB
|
|
Scanning System
|
Progressive
|
|
Electronic Shutter Speed
|
Auto/Manual, 1/3~1/100000s
|
|
Minimum Illumination
|
0.03Lux/F1.4( Color,1/3s,30IRE)
0.3Lux/F1.4( Color,1/30s,30IRE)
0Lux/F1.4(IR on)
|
|
S/N Ratio
|
More than 50dB
|
|
IR Distance
|
Distance up to 60m(197ft)
|
|
IR On/Off Control
|
Auto/ Manual
|
|
IR LEDs
|
4
|
|
Lens
|
|
Lens Type
|
Motorized(-ZS),Manual(-VFS)
|
|
Mount Type
|
Board-in
|
|
Focal Length
|
2.7mm~13.5mm
|
|
Max. Aperture
|
F1.4
|
|
Angle of View
|
H:104°~28°, V:55°~16°
|
|
Focus Control
|
Motorized(-ZS),Manual(-VFS)
|
|
Close Focus Distance
|
0.3m
|
|
DORI Distance
|
Lens
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
W
|
64m(210t)
|
26m(85ft)
|
13m(43ft)
|
6m(20ft)
|
|
T
|
222m(728ft)
|
89m(292ft)
|
44m(144ft)
|
22m(72ft)
|
|
PTZ
|
|
Pan/Tilt Range
|
Pan:0° ~360° ;Tilt:0° ~90° ;Rotation:0° ~360°
|
|
Intelligence
|
|
Event Trigger
|
Motion detection, Video tampering , Scene changing, Network disconnection , IP address conflict, Illegal Access,Storage anomaly
|
|
IVS
|
Tripwire, Intrusion
|
|
Video
|
|
Compression
|
H.265/H.264H/MJPEG(Sub Stream)
|
|
Smart Codec
|
Support H.265+/H.264+
|
|
Streaming Capability
|
2 Streams
|
|
Resolution
|
4M(2688x1520)/3M(2304×1296)/1080P(19
20×1080)/720P(1280×720)/VGA(640×480)/
D1(704×576/704×480)/CIF(352×288/352×240)
|
|
Frame Rate
|
Main Stream: 4M (1 ~ 20fps)/3M(1 ~ 25/30fps)
|
|
Sub Stream: D1/CIF(1 ~ 25/30fps)
|
|
Bit Rate Control
|
CBR/VBR
|
