Camera
|
Image Sensor
|
1/2.5” 8Megapixel progressive scan CMOS
|
Effective Pixels
|
3840(H)x2160(V)
|
RAM/ROM
|
512MB/32MB
|
Scanning System
|
Progressive
|
Electronic Shutter Speed
|
Auto/Manual, 1/3(4)~1/100000s
|
Minimum Illumination
|
0.03Lux/F2.5( Color,1/3s,30IRE)
0.3Lux/F2.5( Color,1/30s,30IRE)
0Lux/F2.5(IR on)
|
S/N Ratio
|
More than 50dB
|
IR Distance
|
Distance up to 50m (164ft)
|
IR On/Off Control
|
Auto/ Manual
|
IR LEDs
|
1
|
Lens
|
Lens Type
|
Fixed
|
Mount Type
|
Board-in
|
Focal Length
|
2.8mm (4mm optional)
|
Max. Aperture
|
F2.5 (F2.2)
|
Angle of View
|
H:112° (88°), V:69° (48°)
|
Optical Zoom
|
N/A
|
Focus Control
|
Fixed
|
Close Focus Distance
|
0.9m(1.7m)
|
DORI Distance
|
Lens
|
Detect
|
Observe
|
Recognize
|
Identify
|
2.8 mm
|
69m(226ft)
|
28m(92ft)
|
14m(46ft)
|
7m(23ft)
|
4.0 mm
|
89m(292ft)
|
36m(118ft)
|
18m(59ft)
|
9m(30ft)
|
Pan/Tilt/Rotation
|
Pan/Tilt/Rotation Range
|
Pan:0˚~360˚; Tilt:0˚~78˚; Rotation:0˚~360˚
|
Intelligence
|
IVS
|
Tripwire, Intrusion, Object Abandoned/Missing
|
Advanced Intelligent Functions
|
Face Detection
|
Video
|
Compression
|
H.265+/H.265/H.264+/H.264
|
Streaming Capability
|
3 Streams
|
Resolution
|
4K(3840×2160)/6M(3072×2048)/5M(2560×1920)/
3M(2048x1536)/3M(2304×1296)/
1080P(1920×1080)/1.3M(1280x960)/
720P(1280×720)/D1(704×576/704×480) /VGA(640×480)/CIF(352×288/352×240)
|
Frame Rate
|
Main Stream: 4K(1~15fps)/3M(1~25/30fps)
|
Sub Stream: D1(1~25/30fps)
|
Third Stream: 1080P(1~25/30fps)
|
Bit Rate Control
|
CBR/VBR
|
Bit Rate
|
H.264: 24K ~ 10240Kbps
H.265: 14K ~ 9984Kbps
|
Day/Night
|
Auto(ICR) / Color / B/W
|
BLC Mode
|
BLC / HLC / WDR(120dB)
|
