Camera
|
|
Image Sensor
|
1/3” 4Megapixel progressive scan CMOS
|
|
Effective Pixels
|
2688(H)x1520(V)
|
|
RAM/ROM
|
512MB/32MB
|
|
Scanning System
|
Progressive
|
|
Electronic Shutter Speed
|
Auto/Manual, 1/3(4)~1/100000s
|
|
Minimum Illumination
|
0.08Lux/F2.0( Color,1/3s,30IRE)
0.3Lux/2.0( Color,1/30s,30IRE)
0Lux/F2.0(IR on)
|
|
S/N Ratio
|
More than 50dB
|
|
IR Distance
|
Distance up to 50m (164ft)
|
|
IR On/Off Control
|
Auto/ Manual
|
|
IR LEDs
|
1
|
|
Lens
|
|
Lens Type
|
Fixed
|
|
Mount Type
|
Board-in
|
|
Focal Length
|
2.8mm (3.6mm, 6mm optional)
|
|
Max. Aperture
|
F2.0 (F2.0, F2.0)
|
|
Angle of View
|
H:104° (87°, 55°), V:57° (48°, 31°)
|
|
Optical Zoom
|
N/A
|
|
Focus Control
|
Fixed
|
|
Close Focus Distance
|
N/A
|
|
DORI Distance
|
Lens
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
2.8 mm
|
63m(207ft)
|
25m(82ft)
|
13m(43ft)
|
6m(20ft)
|
|
3.6 mm
|
80m(262ft)
|
32m(105ft)
|
16m(52ft)
|
8m(26ft)
|
|
6.0 mm
|
117m(384ft)
|
47m(154ft)
|
23m(75ft)
|
12m(39ft)
|
|
Pan/Tilt/Rotation
|
|
Pan/Tilt/Rotation Range
|
Pan:0˚~360˚; Tilt:0˚~78˚; Rotation:0˚~360˚
|
|
Intelligence
|
|
IVS
|
Tripwire, Intrusion, Object Abandoned/Missing
|
|
Advanced Intelligent Functions
|
Face Detection
|
|
Video
|
|
Compression
|
H.265+/H.265/H.264+/H.264
|
|
Streaming Capability
|
3 Streams
|
|
Resolution
|
4M(2688×1520)/3M(2304×1296)/
1080P(1920×1080)/1.3M(1280x960)/
720P(1280×720)/D1(704×576/704×480)/
VGA(640×480)/CIF(352×288/352×240)
|
|
Frame Rate
|
Main Stream: 4M(1~25/30fps)
|
|
Sub Stream: D1(1~25/30fps)
|
|
Third Stream: 720P(1~25/10fps)
|
|
Bit Rate Control
|
CBR/VBR
|
|
Bit Rate
|
H.264: 24~10240Kbps
H.265: 14~9984Kbps
|
|
Day/Night
|
Auto(ICR) / Color / B/W
|
|
BLC Mode
|
BLC / HLC / WDR(120dB)
|
